Izimu

The latest generation to proudly wear the Izimu name. It's our proven DH rig complete with a fresh look and our exclusive XPI geometry adjustment technology.

Features

  • 203mm REAR TRAVEL (7")
  • 180mm - 200mm (REC. FORK)
  • FOX RC2
  • Colours: Yellow/Blue & Red or Black/Blue & Yellow

Technology

XPI

Frame Specs

Izimu 2013 Frame Specs

Tapered 1 1/8" to 1.5" (44mmx49mm) head tube 12 x 150mm rear hub spacing
Syntace X12 rear axle 73mm ISCG 05 bottom bracket
CNC machined 6082 Ali 12 x 150mm bolt thru rear axle XPI geometry adjust
Shock option: FOX VAN RC 200mm [8"] rear wheel travel
241mm x 76mm [9.5" x 3"] rear shock length Hydroformed top tube
Postmount 160mm rear brake tab Custom drawn Al 6082 T6 tubeset
Small, medium and large frame sizes 4.7kgs Frame weight (with coil shock)
  • Tapered 1 1/8" to 1.5" (44mmx49mm) head tube
  • 12 x 150mm rear hub spacing
  • Syntace X12 rear axle
  • 73mm ISCG 05 bottom bracket
  • CNC machined 6082 Ali 12 x 150mm bolt thru rear axle
  • XPI geometry adjust
  • Shock option: FOX VAN RC
  • 200mm [8"] rear wheel travel
  • 241mm x 76mm [9.5" x 3"] rear shock length
  • Hydroformed top tube
  • Postmount 160mm rear brake tab
  • Custom drawn Al 6082 T6 tubeset
  • Small, medium and large frame sizes
  • 4.7kgs Frame weight (with coil shock)

European Build

European build specification by Sports Nut GmbH

Izimu 2013 Build Specs (Air)

Frame Drivetrain Components
Rear Shock
FOX Van RC		 Derailleur (F)
-		 Brake (F)
Formula The 1s 203mm, black
Fork
Rock Shox Boxxer RCCL 200mm, black		 Derailleur (R)
SRAM X.0 Type 2 short, 10-speed, blue		 Brake (R)
Formula The 1s 180 mm, black
Wheels Shifter front
-		 Headset
Acros AX03, black
Rims
Spank Subrosa 26", matt blue		 Shifter rear
SRAM TRIGGER X.9 RR, 10-speed, black		 Bar
Spank Spike 777, 15 mm rise, matt blue
Tires (F)
Onza IBEX DH 61-559 45a		 Crank
E.13 LG1 (170 mm, 38t), black		 Stem
Spank Director, matt blue
Tires (R)
Onza IBEX DH 61-559 55a		 Chainguide
E.13 LS1+ (ISCG05, 36-40t), black		 Grips
Spank Lock On grips, black w/ blue endrings
Hub (F)
Atomlab Pimplite 20 mm, black		 Chain
SRAM PC1031, 10-speed		 Seat
SDG i-Fly, black
Hub (R)
Atomlab Pimplite 12/150 mm, black		 Cassette
SRAM PG-1030, 11-26t, 10-speed		 Seatpost
SDG Micro X-Beam, 30.9 mm
  • Rear Shock
    FOX Van RC
  • Derailleur (F)
    -
  • Brake (F)
    Formula The 1s 203mm, black
  • Fork
    Rock Shox Boxxer RCCL 200mm, black
  • Derailleur (R)
    SRAM X.0 Type 2 short, 10-speed, blue
  • Brake (R)
    Formula The 1s 180 mm, black
  • Shifter front
    -
  • Headset
    Acros AX03, black
  • Rims
    Spank Subrosa 26", matt blue
  • Shifter rear
    SRAM TRIGGER X.9 RR, 10-speed, black
  • Bar
    Spank Spike 777, 15 mm rise, matt blue
  • Tires (F)
    Onza IBEX DH 61-559 45a
  • Crank
    E.13 LG1 (170 mm, 38t), black
  • Stem
    Spank Director, matt blue
  • Tires (R)
    Onza IBEX DH 61-559 55a
  • Chainguide
    E.13 LS1+ (ISCG05, 36-40t), black
  • Grips
    Spank Lock On grips, black w/ blue endrings
  • Hub (F)
    Atomlab Pimplite 20 mm, black
  • Chain
    SRAM PC1031, 10-speed
  • Seat
    SDG i-Fly, black
  • Hub (R)
    Atomlab Pimplite 12/150 mm, black
  • Cassette
    SRAM PG-1030, 11-26t, 10-speed
  • Seatpost
    SDG Micro X-Beam, 30.9 mm

Geometry

Size Top Tube Reach Stack Seat Tube Chainstay Wheelbase Head Angle Seat Angle BB Height Head Tube Shock Fork
Small 565mm 366mm 579mm 390mm 442mm 1138mm 65° 71° +30 120mm 9.5' x 3'
241 x 76mm		 565mm
Medium 595mm 396mm 579mm 400mm 442mm 1168mm 65° 71° +30 120mm 565mm
Large 625mm 426mm 579mm 410mm 442mm 1198mm 65° 71° +30 120mm 565mm
Izimu 2013 Geometry
SizeSmall
Top Tube565mm
Reach366mm
Stack579mm
Seat Tube390mm
Chainstay442mm
Wheelbase1138mm
Head Angle65°
Seat Angle71°
BB Height+30
Head Tube120mm
Shock9.5' x 3'
241 x 76mm
Fork565mm
SizeMedium
Top Tube595mm
Reach396mm
Stack579mm
Seat Tube400mm
Chainstay442mm
Wheelbase1168mm
Head Angle65°
Seat Angle71°
BB Height+30
Head Tube120mm
Shock9.5' x 3'
241 x 76mm
Fork565mm
SizeLarge
Top Tube625mm
Reach426mm
Stack579mm
Seat Tube410mm
Chainstay442mm
Wheelbase1198mm
Head Angle65°
Seat Angle71°
BB Height+30
Head Tube120mm
Shock9.5' x 3'
241 x 76mm
Fork565mm

XPI

Simple Geometry Adjustment with XPI

Simple and effective geometry adjustment

In 2011 the XPI will be offered as a standard feature on the Izimu frames and will be available as an optional after-market upgrade for the 2011 180mm freeride frames.

XPI offers riders simple and effective geometry adjustments in a lightweight, neat and compact design. Using an offset eccentric at the heart of the design, the XPI pivot allows riders to fine-tune chainstay length [wheelbase], headtube angle and bottom bracket height within a wide range of usable parameters.

These adjustments can be made quickly and easily with the need of only two allen keys. The XPI pivot cap has four settings for base-level adjustments, with a standard fork setup.

Standard setting

Slacker head angle, lower BB, longer chainstay

Standard setting, shorter chainstay

Steeper head angle, higher BB, shorter chainstay

BB Height and wheelbase can be fine-tuned across the settings above
